TECHTONGDA Line Boring Machine, 110V Portable Hole Drilling Connecting Rod Boring Machine, Processing Hole Diameter 1.4'-3.15', 1.18' x 63' Bore Bar

Product features1 Driving of hole drilling machine.By adopting 110V AC servo motorwith characteristics of low-speed of revolution and high torque, the complete machine can realize stationary machining in superior performance.2 No vibration in end travel and cutting process.3 Feeding and processing can realize elect rode less speed regulation. Feeding process can be set according to demands, and processing can automatically stop after reaching the Innit switch.4 Boring bar adopting high-strength alloy and structural st eels featured with high hardness, high accuracy, high tenacity, good abrasion resistance, etc.5 In effective travel, the tool rest can be fixed at any position of boring bar.6 The boring bar can be disassembled separately to make installation.7 ELectric motor controller is equipped with immediately brake program to Avoid vibration in shut down8 The control Cabinet is installed below the main engine to be beneficial to safety operation.ParameterThe maximum processing hole diameter: 3.15in/80mmThe minimum processing hole diameter: 1.4in/35mmThe maximum processing travel: 11.8in/300mmThe maximum feed depth: 3mm on one side (A3steel)Surface roughness: Ra3.2Deviation form circular form<0.02mmGross weight of equipment: 216lb/98kgPower supply: 110V60HzVoltage: 1500WBoring bar length: 5.24ft /1600mmDiameter: 1.18in/30mmItem Included(022780): 1 Set of Hole Drilling Machine for Engineering Machinery

Item details

• ASIN : B0FDQ6627L
• Brand Name : TECHTONGDA
• Manufacturer : TECHTONGDA
• Part Number : L022780
• UPC : 198462109444
• Unit Count : 1.0 Count

Materials & Care

• Material Type : Alloy Steel
• Surface Recommendation : Alloy Steel, Cast Iron, Metal
